Argo Race Jacks set the standards for quality and performance in the high performance jack industry.Argo Race Jacks are built for speed and durability at our plant in Wasco, Illinois and feature our exclusive CAD/CAM design for optimum performance. All Argo Race Jacks incorporate similar features from the “heart of the jack”aluminum power unit, to the flex shaft for handle pressure release, and modular, easily replaced components for field service. Argo Race Jacks are offered in various styles from the Sport model to the 1 pump Winston Cup model. Argo Race Jacks are race proven with more than ten years of track service in all areas of racing from weekly racers up through the NASCAR Monster Cup circuit!

ARGO JACKS

Sport Jack The Sport Jack was designed for the weekly racer to use. This jack continues the Argo Race Jack quality standards in a lower cost unit. Incorporated in the design is the Argo power unit, with steel lift beam and unique monocoque chassis. Lifting Specifications: 3 1/8” flat height; 18” maximum lift;1 3/4” lift per stroke; 5–6 pumps to service height; weight 39 lbs. lbs.



Single Down Jack The workhorse of the Argo Race Jack line. Single piston, all aluminum jack. Lifting Specifications: 3 - 6 pumps to service height; 2 7/16” lift per stroke; 3 3/8” flat height; 18” maximum lift; weight 30 lbs.



Pro Rally Jack This jack continues the Aluminum Series of jacks with the rugged Argo power unit and durable monocoque chassis. The Pro Rally is ideal for applications where additional lift height is needed. Lifting Specifications: 3 1/8” flat height; 21” maximum lift; 2” lift per stroke; 27” over all length; weight 43 lbs.



Double Down Jack Our Standard style of jack utilizing our race proven monocoque chassis and all aluminum lifting beam. The standard configuration for this jack is twin 13/16" dia. pistons for 4 3/16" lift per pump. It can be configured in 3/4", 13/16" or 7/8" dia. pis-tons. For example, a jack using two 7/8" pistons will lift twice as fast as the RP500 but will require twice the effort. Lifting Specifications: 3 3/8” flat height; 18” maximum lift; 2–4 pumps to service height; weight 32 lbs.



Super Pro Rally The Super Pro Rally Jack lifts to 23” high and has larger out-board wheels for stability in high lift applications. Construction is all aluminum for lighter weight. Lifting Specifications: 3 1/8” flat height; 23” maximum lift; 2 3/4” lift per stroke; 30” over all length; weight 40 lbs.



Flat Jack Our Standard style of jack utilizing our race proven monocoque chassis and all aluminum lifting beam. The standard configuration for this jack is twin 13/16" dia. pistons for 4 3/16" lift per pump. It can be configured in 3/4", 13/16" or 7/8" dia. pistons. For example, a jack using two 7/8" pistons will lift twice as fast as the RP500 but will require twice the effort. Lifting Specifications: 1 7/8” flat height; 18” maximum lift; 2–4 pumps to service height; weight 32 lbs.



Pro Race Billet Double Down Jack This custom configured jack lifts from 5"–7 1/2" per stroke and is a true one pump jack. This jack incorporates 7/8" or 15/16" dia. pistons, Q-lift beam and billet components for maximum lift per stroke. Lifting Specifications: 1 pump to service height; up to 71/2” lift per stroke



Pro Sport Jack A traditional type of jack utilizing aluminum side plates and interlocking steel spacers for rigidity and strength. The Pro Sport series is offered in either 1 3/4" or 2 7/16" lift per stroke. Lifting Specifications: 3 3/16” flat height; 18” maximum lift; 3–6 pumps to service height;weight 34 lbs.



Pro Race Double Down Jack A traditional side plate style jack with aluminum side plates, aluminum lifting beam and interlocking steel spacers for rigidity . This jack is offered in lifts of 4 3/16" to 5" per stroke and comes with a 1 1/4" dia. steel handle. Lifting Specifications: 3 3/8” flat height; 18” maximum lift;1–2 pumps to service height; weight 31 lbs.



Low Jack A 3 1/4" height at the lift pad and a 4 1/4" height at the lift beam pivot pin make this truly the low jack in the performance jack industry. Lifting Specifications: 3 1/4” flat height; 2 1/4" lift per stroke; 17” maximum lift; 3–6pumps to service height; weight 33 lbs.



Jack Accessories

The Super Pro Rally Jack

The Flat Jack

Pro Race Billet Double Down Jack

The Low Jack

Dirt Wing Kit (Sport Jack Series) The dirt wing kit easily bolts into place on any Argo Jack. A 1/4” larger diameter front roller and 16” wide aluminum channel adapts the jack for use on either paved or non-paved surfaces.

(Pro Sport & Pro Race) Easily add to any Pro Sport or Pro Race jack by bolting wings onto the sideplates without changing the front roller.
